Details
Parameters
Color of emission
Infrared (>800 nm)
Current
IF
1000
mA
Peak wavelength
λ
860
nm
Brightness
ΦE
1300
mW
IE
1350
mW/sr
Beam angle
∢
50
°
Dimension
l
3.75
mm
w
3.75
mm
h
2.9
mm
Operating temperature
Top
min.
-40
°C
Top
max.
125
°C
Application fields
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| SFH 4718AS A01 | Ie = 1120 ... 1800 mW/sr, (Ie=1350 mW/sr typ.) (IF = 1000 mA) | Q65113A3411 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
