Details
Parameters
Color of emission
Infrared (>800 nm)
Current
IF
1000
mA
Peak wavelength
Ī»
860
nm
Brightness
Ī¦E
800
mW
IE
230
mW/sr
Beam angle
ā¢
130
Ā°
Dimension
l
1.6
mm
w
1.6
mm
h
1.33
mm
Operating temperature
Top
min.
-40
Ā°C
Top
max.
105
Ā°C
Application fields
Medical & health
Medical Lighting
Ordering codes
Product Type | Description | Order No. | Availability |
---|---|---|---|
SFH 4172 | Ie = 180 ... 280 mW/sr, (Ie=230 mW/sr typ.) (IF = 1000 mA) | Q65113A3396 |
Downloads
For software click here/for further documents visit our
download center
Application note
Eye safety of IREDs used in lamp applications
Product related
High-speed switching of IR-LEDs ā Background and data sheet definition
Product related
Customer complaint management ā Details on return shipments for failure analysis request (FAR)
General information
Handling of silicon resin LEDs
Handling recommendations
Dry pack information
Handling recommendations
Fundamentals of LED handling
Handling recommendations
Measuring of the temperature profile during the reflow solder process
Soldering and processing
Processing of SMD LEDs
Soldering and processing
Recommended pick-and-place tools of LEDs
Soldering and processing
PCB technologies for LED applications
Thermal management
Resources
CAD Data
CAD Data
Optical Simulation
Optical Simulation
Images
SFH_4172__OSLON P1616 with flat 130Ā° lens_36x22.4mm_cmyk
