Details
Parameters
Color of emission
Infrared (>800 nm)
Current
IF
1000
mA
Peak wavelength
Ī»
860
nm
Brightness
Ī¦E
700
mW
IE
190
mW/sr
Beam angle
ā¢
90
Ā°
ā¢
140
Ā°
Dimension
l
1.6
mm
w
1.6
mm
h
1.38
mm
Operating temperature
Top
min.
-40
Ā°C
Top
max.
105
Ā°C
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| SFH 41747 | Ie = 140 ... 224 mW/sr, (Ie=190 mW/sr typ.) (IF = 1000 mA) | Q65113A3452 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
