Details
Parameters
Color of emission
Infrared (>800 nm)
Current
IF
1000
mA
Peak wavelength
Ī»
940
nm
Brightness
Ī¦E
1485
mW
IE
325
mW/sr
Beam angle
ā¢
130
Ā°
Dimension
l
1.6
mm
w
1.6
mm
h
0.81
mm
Operating temperature
Top
min.
-40
Ā°C
Top
max.
105
Ā°C
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| SFH 4180BS-FA2FB2-1113 | Ī¦e = 1250 ... 1800 mW, (Ī¦e=1485 mW typ.) (IF = 1000 mA) | Q65113A8781 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
| SFH 4180BS-FA2FB2-11 | Ī¦e = 1250 ... 1800 mW, (Ī¦e=1485 mW typ.) (IF = 1000 mA) | Q65113A4988 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
| SFH 4180BS-FA2FB2-13 | Ī¦e = 1250 ... 1800 mW, (Ī¦e=1485 mW typ.) (IF = 1000 mA) | Q65113A8780 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
