Details
Parameters
Color of emission
Infrared (>800 nm)
Current
IF
1000
mA
Peak wavelength
λ
820
nm
Brightness
ΦE
660
mW
IE
3200
mW/sr
Beam angle
∢
20
°
Dimension
l
3.5
mm
w
3.5
mm
h
2.39
mm
Operating temperature
Top
min.
-40
°C
Top
max.
85
°C
Ordering information
| Product Type | Description | Ordering code | Availability |
|---|---|---|---|
| SFH 4780S | Ie = 2400 ... 4850 mW/sr, (Ie=3200 mW/sr typ.) (IF = 1000 mA) | Q65111A6054 | Discontinued |
