Details
Parameters
Color of emission
Infrared (>800 nm)
Current
IF
1000
mA
Peak wavelength
Ī»
860
nm
Brightness
Ī¦E
530
mW
IE
180
mW/sr
Beam angle
ā¢
120
Ā°
Dimension
l
11.0
mm
w
6.0
mm
h
1.8
mm
Operating temperature
Top
min.
-40
Ā°C
Top
max.
125
Ā°C
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| SFH 4232-Z | Ī¦e = 320 ... 800 mW, (Ī¦e=530 mW typ.) (IF = 1000 mA) | Q65110A8754 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
