Details
Parameters
Color of emission
Infrared (>800 nm)
Current
IF
100
mA
Peak wavelength
λ
860
nm
Brightness
ΦE
76
mW
IE
25
mW/sr
Beam angle
∢
120
°
Dimension
l
3.5
mm
w
2.8
mm
h
1.9
mm
Operating temperature
Top
min.
-40
°C
Top
max.
110
°C
Ordering information
| Product Type | Description | Ordering code | Availability |
|---|---|---|---|
| SFH 4250B | Ie = 22.4 ... 35.5 mW/sr, (Ie=25 mW/sr typ.) (IF = 100 mA) | Q65113A9363 | Full production |
