Replacement Products
Details
Parameters
Color of emission
Infrared (>800 nm)
Current
IF
20
mA
Peak wavelength
λ
950
nm
Brightness
ΦE
12
mW
IE
35
mW/sr
Beam angle
∢
18
°
Dimension
l
3.0
mm
w
4.0
mm
h
2.9
mm
Operating temperature
Top
min.
-40
°C
Top
max.
85
°C
Application fields
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| SFH 4141 | Ie = 16 ... 80 mW/sr, (Ie=35 mW/sr typ.) (IF = 20 mA) | Q65111A6138 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
