Details
Parameters
Color of emission
Infrared (>800 nm)
Current
IF
100
mA
Peak wavelength
λ
950
nm
Brightness
ΦE
55
mW
IE
50
mW/sr
Beam angle
∢
60
°
Dimension
l
5.5
mm
w
5.5
mm
h
6.6
mm
Operating temperature
Top
min.
-40
°C
Top
max.
100
°C
Application fields
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| SFH 4547 | Ie = 28 ... 112 mW/sr, (Ie=50 mW/sr typ.) (IF = 100 mA) | Q65111A1141 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
