Details
Parameters
Color of emission
Infrared (>800 nm)
Current
IF
100
mA
Peak wavelength
λ
860
nm
Brightness
ΦE
70
mW
IE
200
mW/sr
Beam angle
∢
26
°
Dimension
l
3.8
mm
w
3.8
mm
h
4.85
mm
Operating temperature
Top
min.
-40
°C
Top
max.
100
°C
