Details
Parameters
Color of emission
Infrared (>800 nm)
Current
IF
1000
mA
Peak wavelength
λ
940
nm
Brightness
ΦE
1550
mW
IE
1080
mW/sr
Beam angle
∢
60
°
Dimension
l
3.85
mm
w
3.85
mm
h
2.29
mm
Operating temperature
Top
min.
-40
°C
Top
max.
105
°C
Ordering information
| Product Type | Description | Ordering code | Availability |
|---|---|---|---|
| SFH 4795BS-EB1FA1-11 | Ie = 900 ... 1250 mW/sr, (Ie=1030 mW/sr typ.) (IF = 1000 mA) | Q65113A8826 | Full production |
| SFH 4795BS-EB1FA1-1113 | Ie = 900 ... 1250 mW/sr, (Ie=1030 mW/sr typ.) (IF = 1000 mA) | Q65113A8827 | Full production |
| SFH 4795BS-EB1FA1-13 | Ie = 900 ... 1250 mW/sr, (Ie=1030 mW/sr typ.) (IF = 1000 mA) | Q65113A8825 | Full production |
