Details
Parameters
Color of emission
Red (612-630 nm)
True Green (513-545 nm)
Blue (450-480 nm)
Electrical power
0.041
W
0.064
W
0.057
W
Low
Low
Low
Brightness
ΦV
2.14
lm
IV
0.75
cd
ΦE
11.8
mW
IE
4.15
mW/sr
Beam angle
∢
120
°
Operating temperature
Top
min.
-40
°C
Top
max.
110
°C
Dimension
l
3.4
mm
w
3.3
mm
h
1.8
mm
Application fields
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| LRTBGVSG-UEVE-24+AMAQ-29+SCUC-HR |
|
Q65111A3732 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
