Details
Parameters
Color of emission
White
Electrical power
1.1
W
High
Brightness
ΦV
101
lm
IV
33.4
cd
ΦE
323
mW
IE
107
mW/sr
Beam angle
∢
120
°
Operating temperature
Top
min.
-40
°C
Top
max.
125
°C
Dimension
l
11.0
mm
w
6.0
mm
h
1.8
mm
Application fields
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| LW W5SM-KXLX-JKQL-24E4 | ΦV = 71 ... 130 lm (IF = 350 mA) | Q65111A8469 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
