Details
Parameters
Color of emission
White
CRI
70
Electrical power
0.99
W
High
Brightness
ΦV
240
lm
IV
79.4
cd
ΦE
1500
mW
IE
496
mW/sr
Beam angle
∢
120
°
Operating temperature
Top
min.
-40
°C
Top
max.
105
°C
Dimension
l
5.0
mm
w
5.0
mm
h
0.7
mm
Application fields
Ordering codes
Product Type | Description | Order No. | Availability |
---|---|---|---|
GW Q9LR34.PM-L9M8-XX510-1 | ΦV = 170.0 ... 260.0 lm, 2200 K (IF = 45 mA) | Q65113A4744 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
By clicking this button you will be transferred to the dedicated site of our logistics partner, Mouser Electronics where your purchase can be completed. Your payment and order details provided for this purpose will be shared between Mouser Electronics and ams OSRAM. More details on the data processing in question can be found in the Privacy Policy of the Mouser shop.
|
GW Q9LR34.PM-M4N3-XX56-1 | ΦV = 210.0 ... 310.0 lm, 3500 K (IF = 45 mA) | Q65113A4737 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
By clicking this button you will be transferred to the dedicated site of our logistics partner, Mouser Electronics where your purchase can be completed. Your payment and order details provided for this purpose will be shared between Mouser Electronics and ams OSRAM. More details on the data processing in question can be found in the Privacy Policy of the Mouser shop.
|
GW Q9LR34.PM-M3N2-XX51-1 | ΦV = 200.0 ... 300.0 lm, 6500 K (IF = 45 mA) | Q65113A4742 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
By clicking this button you will be transferred to the dedicated site of our logistics partner, Mouser Electronics where your purchase can be completed. Your payment and order details provided for this purpose will be shared between Mouser Electronics and ams OSRAM. More details on the data processing in question can be found in the Privacy Policy of the Mouser shop.
|
GW Q9LR34.PM-M2N1-XX58-1 | ΦV = 190.0 ... 290.0 lm, 2700 K (IF = 45 mA) | Q65113A4743 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
By clicking this button you will be transferred to the dedicated site of our logistics partner, Mouser Electronics where your purchase can be completed. Your payment and order details provided for this purpose will be shared between Mouser Electronics and ams OSRAM. More details on the data processing in question can be found in the Privacy Policy of the Mouser shop.
|
GW Q9LR34.PM-M5N3-XX53-1 | ΦV = 220.0 ... 310.0 lm, 5000 K (IF = 45 mA) | Q65113A4736 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
By clicking this button you will be transferred to the dedicated site of our logistics partner, Mouser Electronics where your purchase can be completed. Your payment and order details provided for this purpose will be shared between Mouser Electronics and ams OSRAM. More details on the data processing in question can be found in the Privacy Policy of the Mouser shop.
|
GW Q9LR34.PM-M4N3-XX52-1 | ΦV = 210.0 ... 310.0 lm, 5700 K (IF = 45 mA) | Q65113A4740 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
By clicking this button you will be transferred to the dedicated site of our logistics partner, Mouser Electronics where your purchase can be completed. Your payment and order details provided for this purpose will be shared between Mouser Electronics and ams OSRAM. More details on the data processing in question can be found in the Privacy Policy of the Mouser shop.
|
GW Q9LR34.PM-M4N3-XX55-1 | ΦV = 210.0 ... 310.0 lm, 4000 K (IF = 45 mA) | Q65113A4738 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
By clicking this button you will be transferred to the dedicated site of our logistics partner, Mouser Electronics where your purchase can be completed. Your payment and order details provided for this purpose will be shared between Mouser Electronics and ams OSRAM. More details on the data processing in question can be found in the Privacy Policy of the Mouser shop.
|
GW Q9LR34.PM-M5N3-XX55-1 | ΦV = 220.0 ... 310.0 lm, 4000 K (IF = 45 mA) | Q65113A4757 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
By clicking this button you will be transferred to the dedicated site of our logistics partner, Mouser Electronics where your purchase can be completed. Your payment and order details provided for this purpose will be shared between Mouser Electronics and ams OSRAM. More details on the data processing in question can be found in the Privacy Policy of the Mouser shop.
|
GW Q9LR34.PM-M3N2-XX57-1 | ΦV = 200.0 ... 300.0 lm, 3000 K (IF = 45 mA) | Q65113A4741 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
By clicking this button you will be transferred to the dedicated site of our logistics partner, Mouser Electronics where your purchase can be completed. Your payment and order details provided for this purpose will be shared between Mouser Electronics and ams OSRAM. More details on the data processing in question can be found in the Privacy Policy of the Mouser shop.
|
GW Q9LR34.PM-M4N3-XX53-1 | ΦV = 210.0 ... 310.0 lm, 5000 K (IF = 45 mA) | Q65113A4739 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
By clicking this button you will be transferred to the dedicated site of our logistics partner, Mouser Electronics where your purchase can be completed. Your payment and order details provided for this purpose will be shared between Mouser Electronics and ams OSRAM. More details on the data processing in question can be found in the Privacy Policy of the Mouser shop.
|
