Details
Parameters
Color of emission
White
CRI
80
Electrical power
0.98
W
High
Brightness
ΦV
141
lm
IV
46.7
cd
ΦE
428
mW
IE
142
mW/sr
Beam angle
∢
120
°
Operating temperature
Top
min.
-40
°C
Top
max.
100
°C
Dimension
l
1.4
mm
w
1.4
mm
h
0.75
mm
Application fields
Medical & health
Medical Lighting
Ordering codes
Product Type | Description | Order No. | Availability |
---|---|---|---|
GW VJLPL1.EM-K5LZ-XX57-1 | ΦV = 125 ... 155 lm, 3000 K (IF = 350 mA) | Q65113A7119 | |
GW VJLPL1.EM-LVL1-XX56-1 | ΦV = 130 ... 160 lm, 3500 K (IF = 350 mA) | Q65113A7118 | |
GW VJLPL1.EM-K4LY-XX58-1 | ΦV = 120 ... 150 lm, 2700 K (IF = 350 mA) | Q65113A7116 | |
GW VJLPL1.EM-LXL3-XX53-1 | ΦV = 140 ... 170 lm, 5000 K (IF = 350 mA) | Q65113A7121 | |
GW VJLPL1.EM-LSK5-XX510-1 | ΦV = 100 ... 130 lm, 2200 K (IF = 350 mA) | Q65113A7117 | |
GW VJLPL1.EM-LWL2-XX55-1 | ΦV = 135 ... 165 lm, 4000 K (IF = 350 mA) | Q65113A7120 |
