Details
Parameters
Color of emission
White
CRI
90
Electrical power
24.0
W
Ultra High
Brightness
ΦV
4160
lm
IV
1390
cd
ΦE
14200
mW
IE
4760
mW/sr
Beam angle
∢
120
°
Operating temperature
Top
min.
-40
°C
Top
max.
105
°C
Dimension
l
19.0
mm
w
19.0
mm
h
1.5
mm
Application fields
Ordering information
| Product Type | Description | Ordering code | Availability |
|---|---|---|---|
| GW KAGMB9.KM-F17-27S3 | ΦV = 3630 ... 4300 lm, 2700 K (IF = 720 mA) | Q65115A1914 | Full production |
| GW KAGMB9.KM-F18-30S3 | ΦV = 3820 ... 4525 lm, 3000 K (IF = 720 mA) | Q65115A1915 | Full production |
| GW KAGMB9.KM-F19-35S3 | ΦV = 3885 ... 4600 lm, 3500 K (IF = 720 mA) | Q65115A1901 | Full production |
| GW KAGMB9.KM-F20-40S3 | ΦV = 3935 ... 4660 lm, 4000 K (IF = 720 mA) | Q65115A1889 | Full production |
| GW KAGMB9.KM-F20-57S3 | ΦV = 3935 ... 4660 lm, 5700 K (IF = 720 mA) | Q65115A1887 | Full production |
| GW KAGMB9.KM-F21-50S3 | ΦV = 3955 ... 4680 lm, 5000 K (IF = 720 mA) | Q65115A1888 | Full production |
| GW KAGMB9.KM-F22-65S3 | ΦV = 3925 ... 4650 lm, 6500 K (IF = 720 mA) | Q65115A1886 | Full production |
