Details
Parameters
Color of emission
White
CRI
96
Electrical power
11
W
Ultra High
Brightness
ΦV
1290
lm
IV
495
cd
ΦE
4720
mW
IE
1810
mW/sr
Beam angle
∢
110
°
Operating temperature
Top
min.
-40
°C
Top
max.
105
°C
Dimension
l
15.8
mm
w
15.8
mm
h
1.15
mm
Application fields
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| GW KAFFBB.GM-D3-35A2D2 | ΦV = 1261 ... 1393 lm, 3500 K (IF = 300 mA) | Q65113A7101 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
| GW KAFFBB.GM-D4-40A2D2 | ΦV = 1314 ... 1452 lm, 4000 K (IF = 300 mA) | Q65113A7100 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
| GW KAFFBB.GM-D2-30A2D2 | ΦV = 1199 ... 1325 lm, 3000 K (IF = 300 mA) | Q65113A7102 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
| GW KAFFBB.GM-D13-50A2D2 | ΦV = 1340 ... 1490 lm, 5000 K (IF = 300 mA) | Q65113A9300 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
| GW KAFFBB.GM-D1-27A2D2 | ΦV = 1137 ... 1257 lm, 2700 K (IF = 300 mA) | Q65113A7103 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
