Details
Parameters
Color of emission
White
CRI
96
Electrical power
18
W
Ultra High
Brightness
ΦV
2160
lm
IV
826
cd
ΦE
7870
mW
IE
3010
mW/sr
Beam angle
∢
110
°
Operating temperature
Top
min.
-40
°C
Top
max.
105
°C
Dimension
l
15.8
mm
w
15.8
mm
h
1.15
mm
Application fields
Ordering codes
Product Type | Description | Order No. | Availability |
---|---|---|---|
GW KAFJBB.GM-E1-27A2D2 | ΦV = 1860 ... 2056 lm, 2700 K (IF = 500 mA) | Q65113A7099 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
GW KAFJBB.GM-E13-50A2D2 | ΦV = 2130 ... 2360 lm, 5000 K (IF = 500 mA) | Q65113A9295 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
GW KAFJBB.GM-E4-40A2D2 | ΦV = 2111 ... 2333 lm, 4000 K (IF = 500 mA) | Q65113A7097 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
GW KAFJBB.GM-E2-30A2D2 | ΦV = 1917 ... 2119 lm, 3000 K (IF = 500 mA) | Q65113A7098 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
GW KAFJBB.GM-E3-35A2D2 | ΦV = 2020 ... 2232 lm, 3500 K (IF = 500 mA) | Q65113A7096 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
