Replacement Products
Details
Parameters
Photocurrent
24.0
µA
Fall time
tf
0.5
µs
Rise time
tf
0.5
µs
Spectral range of sensitivity typ.
λ10%
min.
400
nm
λ10%
max.
1150
nm
Radiant sensitive area
A
1.54
mm²
Beam angle
∢
120
°
Dimension
l
7.6
mm
w
3.9
mm
h
2.05
mm
Operating temperature
Top
min.
-40
°C
Top
max.
80
°C
Application fields
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| BPX 48 | IP = ≥ 15 µA, (IP=24 µA typ.) (Ev=1000.00 lx) | Q62702P0017S001 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
