Details
Parameters
Photocurrent
24.0
µA
Fall time
tf
0.5
µs
Rise time
tf
0.5
µs
Spectral range of sensitivity typ.
λ10%
min.
400
nm
λ10%
max.
1100
nm
Radiant sensitive area
A
1.54
mm²
Beam angle
∢
110
°
Dimension
l
9.25
mm
w
9.25
mm
h
3.2
mm
Operating temperature
Top
min.
-40
°C
Top
max.
125
°C
Application fields
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| SFH 221 | IP = ≥ 15 µA, (IP=24 µA typ.) (Ev=1000 lx) | Q62702P0270 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
