Details
Parameters
Color of emission
Hyper Red (635-666 nm)
Peak wavelength
Ī»
680
nm
Current
IF
9
mA
Brightness
Ī¦E
5.5
mW
Beam angle
ā¢
12
Ā°
ā¢
12
Ā°
Dimension
l
2.7
mm
w
2.0
mm
h
1.3
mm
Operating temperature
Top
min.
-20
Ā°C
Top
max.
50
Ā°C
Application fields
Ordering codes
Product Type | Description | Order No. | Availability |
---|---|---|---|
V100P000A-680 | Popt = 5.5 mW typ. (IF = 9 mA) | Q65113A6388 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
