Details
Parameters
Color of emission
Infrared (>800 nm)
Peak wavelength
Ī»
940
nm
Current
IF
4000
mA
Brightness
Ī¦E
3600
mW
Beam angle
ā¢
18
Ā°
ā¢
18
Ā°
Dimension
l
0.985
mm
w
0.885
mm
h
0.1
mm
Operating temperature
Top
min.
-40
Ā°C
Top
max.
110
Ā°C
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| OLI3539V.A1-940-A | Popt = N/A (N/A), (Popt=3.6 W typ.) | Q65113A1728 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
