Details
Parameters
Color of emission
Super Red (627-639 nm)
Electrical power
0.04
W
Low
Brightness
ΦV
0.265
lm
IV
0.058
cd
ΦE
2.2
mW
IE
0.482
mW/sr
Beam angle
∢
160
°
Operating temperature
Top
min.
-30
°C
Top
max.
85
°C
Dimension
l
1.6
mm
w
0.8
mm
h
0.8
mm
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| LS Q976-NR-1 | Iv = 28 ... 180 mcd (IF = 20 mA) | Q62702P5187 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
