Details
Parameters
Color of emission
Red (612-630 nm)
True Green (513-545 nm)
Blue (450-480 nm)
Electrical power
0.044
W
0.045
W
0.022
W
Low
Low
Low
Brightness
ΦV
2.29
lm
IV
0.69
cd
ΦE
10.7
mW
IE
3.21
mW/sr
Beam angle
∢
120
°
Operating temperature
Top
min.
-40
°C
Top
max.
85
°C
Dimension
l
3.8
mm
w
1.0
mm
h
0.6
mm
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| KRTB AILMS1-5B5C-B1B12 |
|
Q65113A2872 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
