Details
Parameters
Photocurrent
50.0
µA
Fall time
tf
0.005
µs
Rise time
tf
0.005
µs
Spectral range of sensitivity typ.
λ10%
min.
750
nm
λ10%
max.
1100
nm
Radiant sensitive area
A
1.0
mm²
Beam angle
∢
40
°
Dimension
l
5.7
mm
w
5.7
mm
h
8.6
mm
Operating temperature
Top
min.
-40
°C
Top
max.
100
°C
Application fields
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| SFH 203 FA AN23 | IP = ≥ 34 µA, (IP=50 µA typ.) (Ee=1 mW/cm²) | Q62702P0443 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
| SFH 203 FA | IP = ≥ 34 µA, (IP=50 µA typ.) (Ee=1 mW/cm²) | Q62702P0956 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
