Details
Parameters
Color of emission
Infrared (>800 nm)
Current
IF
1000
mA
Peak wavelength
λ
860
nm
Brightness
ΦE
630
mW
IE
270
mW/sr
Beam angle
∢
90
°
Dimension
l
3.85
mm
w
3.85
mm
h
2.29
mm
Operating temperature
Top
min.
-40
°C
Top
max.
125
°C
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| SFH 4715 | Ie = 160 ... 500 mW/sr, (Ie=270 mW/sr typ.) (IF = 1000 mA) | Q65111A2364 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
