Health wearables market heats up with introduction of tiny, ultra-accurate temperature sensor
Enabling medical-grade temperature accuracy optimized for compact, low-power health wearables
The AS6223 is a tiny digital I²C temperature sensor (0.82 mm × 0.82 mm × 0x355mm) optimized for wearables. It delivers ±0.09 °C accuracy in room temperature and body temperature ranges with ultralow power consumption (6 µA active, 0.1 µA standby) and enables straightforward integration into compact medical, consumer health, and IoT devices.
With the introduction of the AS6223, highly accurate temperature sensing can now be integrated into an even broader range of wearable health devices. Small, precise, and operating on microwatts of power, this digital temperature sensor is well suited for medical patches, smartwatches, and smart rings, where space, accuracy, and energy efficiency are critical.
When a patient arrives at a medical clinic feeling unwell, one of the first diagnostic checks is body temperature. Vital parameters such as heart rate and oxygen saturation provide essential information, but core body temperature remains one of the most fundamental indicators in medical assessment.
This is why there is growing interest in wearable health monitoring technologies supported by reliable temperature sensing. With medical patches, smartwatches, and smart rings, continuous logs of physiological parameters become possible — and temperature plays a central role in enabling meaningful interpretation of the data.
As wearable technology evolves, accurate 24/7 temperature monitoring is becoming essential for several advanced use cases:
- Detecting early health changes, using multi-sensor data combined with AI algorithms
- Supporting metabolic and glucose-monitoring systems, where temperature compensation increases accuracy
- Providing contextual information for activity, sleep, and circadian rhythm analysis
- Improving closed-loop insulin delivery, where thermal data enhances calibration of continuous glucose monitors
To support these applications, wearable devices require temperature sensors that fit into millimeter scale enclosures without compromising precision or battery runtime. Alongside temperature sensing, the broader ecosystem also relies on components such as light emitting diodes, photodiodes, optical front ends, and analog front-end ICs, which form the foundation for many vital sign monitoring systems.
Key specs at a glance
Package size: 0.82 mm × 0.82 mm (WLCSP)
Accuracy: ±0.09 °C at temp range from 20 °C to 42 °C
Interface: I²C, support for several addresses
Pin count: 4
Active current: 6.0 µA
Standby current: 0.1 µA
Key technical advantages: ultrasmall footprint for compact system designs
Measuring only 0.82 mm × 0.82 mm, the AS6223 can be integrated into flexible PCBs, smart textiles, or thin medical patches. Its extremely compact footprint frees up additional space for antennas, batteries, or other design critical components.
High precision body temperature measurement
At typical body temperatures around 37°C, the AS6223 achieves ±0.09°C accuracy, supporting medical-grade thermal measurement requirements. This level of precision is essential in applications such as continuous health tracking, glucose monitoring, and advanced physiological analytics.
Simplified integration and fast designing
With its four-pin layout and digital I²C interface, the device integrates easily into a wide range of microcontroller-based systems. Full factory calibration helps designers shorten development cycles and streamline production.
Extremely low power consumption
Operating at 6.0 µA with a 0.1 µA standby current, the sensor supports long battery life in wearables, disposable patches, and energy constrained IoT nodes.
Industrial applications: AS6219 for extended ranges and harsh environments
For applications requiring broader operating ranges or increased robustness — such as cold-chain monitoring, HVAC, building automation, or industrial IoT — the AS6219 offers a suitable alternative with high accuracy across a wider temperature span.
AS6223 vs AS6219 at a glance
| Feature / Parameter | AS6223 (Wearables) | AS6219 (Industrial / HVAC / Cold Chain) |
|---|---|---|
| Package size | 0.82 × 0.82 mm | 1.5 x 1.0mm |
| Accuracy at body temp | ±0.09 °C | 0.99 °C |
| Typical use case focus | Wearables, patches, smart rings | Building automation, HVAC, cold-chain |
| Operating temperature | Optimized around body temperature | Extended industrial range |
| Power consumption | Ultralow | Low |
| Interface | I²C | I²C |
Start evaluating: AS6223 evaluation kit
Temperature sensing continues to grow in importance across health monitoring, medical, industrial, and automation applications. Devices such as the AS6223 and AS6219 combine compact size, accuracy, and low power consumption to support engineers developing next generation systems.
Engineers can explore device performance and integration behavior using dedicated evaluation tools: AS6223 evaluation kit
In addition, evaluation kits for other digital temperature sensors in the portfolio are available; details on the full device range and corresponding evaluation tools can be found on the temperature sensor portfolio page.
