ams AS5200L_MF_EVM_AB Evaluation board



The adapter board of AS5200L allows you to evaluate the AS5200L, one of our automotive qualified dual die sensors, with all its features. The adapterboard consists of the AS5200L position sensor and its necessary external components. All relevant signals are available on a dual-row 2.54mm 4-pin header footprint and can be easily wired to an existing application. To read out the sensor over I2C connect the sensor to a standard microcontroller.

Ordering codes

Product Type Description Order No. Availability


User guides

User guide
