Details
Parameters
Color of emission
True Green (513-545 nm)
Electrical power
8.1
W
Ultra High
Brightness
ΦV
640
lm
IV
287
cd
ΦE
1290
mW
IE
580
mW/sr
Beam angle
∢
100
°
Operating temperature
Top
min.
-40
°C
Top
max.
150
°C
Dimension
l
7.0
mm
w
7.0
mm
h
3.7
mm
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| LZ4-00G108-0000_G2 | ΦV = 695 ... 1357 lm (IF = 700 mA) | Q65113A6762 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
