Details
Parameters
Color of emission
Green (565-575 nm)
Electrical power
4.1
W
High
Brightness
ΦV
1460
lm
IV
331
cd
ΦE
3200
mW
IE
726
mW/sr
Beam angle
∢
130
°
Operating temperature
Top
min.
-40
°C
Top
max.
125
°C
Dimension
l
5.75
mm
w
4.68
mm
h
1.25
mm
Application fields
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| LE CG Q7WP-5R7R-2-AM | ΦV = 1120 ... 1590 lm (IF = 1400 mA) | Q65113A3684 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
| LE CG Q7WP-5R7R-2 | ΦV = 1120 ... 1590 lm (IF = 1400 mA) | Q65113A2450 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
