Details
Features
- Programmable registers
- High sensitivity and NIR enhanced pixel
- Context switching
- On-chip processing
- On-chip advanced power management
- On-chip temperature sensor
- Illumination synchronization trigger
Benefits
- Compact size
- Low active power
- NIR enhanced with high sensitivity
- On-chip noise reduction
- Reduced off-chip processing
- Extended battery operation
- Ideal in low light conditions
Parameters
Resolution
0.16
MP
Shutter type
Global
Frame rate
max.
360
fps
Optical format
1/10"
Pixel pitch
2.79
µm
2.79
µm
Function
area scan
CRA
Yes
Package
CSP
WLO
Package dimension
h
0.545
mm
l
1.79
mm
w
1.79
mm
Cover glass
Anti-reflective coating
CFA option
Mono
ADC mode
8
bit
10
bit
12
bit
Channels
output
1
Interface
output
I²C
Output interface speed
1500
Mbps
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| MIRA016-2QM2WB |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
||
| MIRA016-2QM1D0 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
||
| MIRA016-2QM1WB |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
Downloads
Images
Images
Images
Software
Mira-016 example device driver source for RPi4 Restricted access
Driver
Access required
You have to be approved by ams-OSRAM AG to download this document.
Please sign in or register so we can check if you are allowed to download the document.
Mira-016 reference board design (containing all voltages and clocks) Restricted access
Library
Access required
You have to be approved by ams-OSRAM AG to download this document.
Please sign in or register so we can check if you are allowed to download the document.
