ams AS5140H_SS_EVM_AB Evaluation board

Not for new design
×
Not for new design

Description

The AS5140H Adapter Board allows you an easy-to-use evaluation of the principle function of the AS5140H magnetic position sensor in your own system design. This small factor board includes the position sensor with its necessary external components. All relevant signals are available on a 2.54mm header footprint and can be easily wired to your own application.

Ordering codes

Product Type Description Order No. Availability
AS5140-SS_EK_AB
