Replacement Products
OSRAM SYNIOS® P2720, KY DMLS31.23
This compact LED device is part of the SYNIOS P2720 family. Given the scalability of this product family, it provides full performance and flexibility with just one footprint.
The KY DMLS31.23 product is meant to provide superior light quality in 1 mm² chip size class.
OSRAM OSLON® Compact PL, KY CELNM2.FY
Compact light source with an isolated thermal pad for improved heat dissipation and providing small z-tolerance (+/-35 µm).
The OSLON Compact PL product family meets both excellent brightness in combination with outstanding luminance.
Details
Parameters
Color of emission
Yellow (580-595 nm)
Electrical power
0.92
W
High
Brightness
ΦV
68
lm
IV
22.6
cd
ΦE
136
mW
IE
45.2
mW/sr
Beam angle
∢
120
°
Operating temperature
Top
min.
-40
°C
Top
max.
125
°C
Dimension
l
11.0
mm
w
6.0
mm
h
1.8
mm
Application fields
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| LY W5SM-JXKY-46-J3T3 | ΦV = 45 ... 97 lm (IF = 400 mA) | Q65112A3895 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
| LY W5SM-HZKX-35-J3T3 | ΦV = 39 ... 82 lm (IF = 400 mA) | Q65112A3894 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
