Details
Parameters
Color of emission
Ultraviolet (100-380 nm)
Electrical power
11.0
W
Ultra High
Brightness
ΦV
29.3
lm
IV
10.8
cd
ΦE
4100
mW
IE
1520
mW/sr
Beam angle
∢
110
°
Operating temperature
Top
min.
-40
°C
Top
max.
115
°C
Dimension
l
7.0
mm
w
7.0
mm
h
1.26
mm
Application fields
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| LZ4-04UV0R-0000 | ΦE = 3.8 ... 6.0 W (IF = 700 mA) | Q65113A2058 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
