Details
Parameters
Color of emission
Amber (609-624 nm)
Electrical power
0.3
W
Mid
Brightness
ΦV
26.8
lm
IV
19.8
cd
ΦE
109
mW
IE
80.7
mW/sr
Beam angle
∢
60
°
Operating temperature
Top
min.
-40
°C
Top
max.
125
°C
Dimension
l
3.0
mm
w
3.0
mm
h
2.43
mm
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| LA CN5M-GAHA-24-1 | ΦV = 18.0 ... 35.5 lm (IF = 140 mA) | Q65111A1207 |
