Details
Parameters
Color of emission
Orange (600-609 nm)
Electrical power
0.04
W
Low
Brightness
ΦV
0.701
lm
IV
0.223
cd
ΦE
1.91
mW
IE
0.607
mW/sr
Beam angle
∢
120
°
Operating temperature
Top
min.
-40
°C
Top
max.
100
°C
Dimension
l
3.2
mm
w
2.8
mm
h
1.9
mm
Application fields
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| LO T776-Q2T1-24 | Iv = 90 ... 355 mcd (IF = 20 mA) | Q65110A2219 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
