Details
Parameters
Color of emission
Infrared (>800 nm)
Current
IF
1000
mA
Peak wavelength
λ
820
nm
Brightness
ΦE
650
mW
IE
1000
mW/sr
Beam angle
∢
36
°
Dimension
l
3.5
mm
w
3.5
mm
h
1.6
mm
Operating temperature
Top
min.
-40
°C
Top
max.
85
°C
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| SFH 4787S | Ie = 815 ... 1500 mW/sr, (Ie=1000 mW/sr typ.) (IF = 1000 mA) | Q65112A2090 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
