ams TSL1401CL Linear Array Sensor

ams TSL1401CL Linear Array Sensor
Discontinued
×
Discontinued

Description

The TSL1401CL linear sensor array consists of an 128 × 1 array of photodiodes, associated charge amplifier circuitry, and an internal pixel data-hold function that provides simultaneous integration start and stop times for all pixels. The array is made up of 128 pixels, each of which has a photo-sensitive area of 3524.3 square micrometers. There is 8-μm spacing between pixels. Operation is simplified by internal control logic that require only a serial-input (SI) signal and a clock.
Datasheet
TSL1401CL DS000136
English
Download
Contact us Support

Details

Features

  • 128 sensor element organization
  • 400 DPI sensor pitch
  • High linearity and uniformity
  • Rail-to-rail output swing

Benefits

  • Provides high density pixel count
  • Enables high resolution scanning
  • Enables capacitive threshold sensing
  • Provides full dynamic range
