Details
Features
- Interference filter technology
- 3 channel UVA/B/C sensing
- High dynamic range, adjustable to the application conditions
- Class leading sensitivity
- Broad conversion range
- Extended temperature range
Benefits
- No filter aging or drifts over lifetime and temperature
- Separated UVA/B/C radiation detection incl. daylight (VIS+NIR) blocking
- Sensor settings adjustable from low to bright radiation conditions
- Fast or high accurate radiation and fluorescence detection possible
- Usability in harsh environments
Parameters
Function
spectral sensing
Supply voltage
3.3
V
min.
2.7
V
max.
3.6
V
Interface
input
I²C slave (400kHz)
output
I²C slave (400kHz)
Operating ambient temperature
min.
-40
°C
max.
85
°C
Integrated diffuser
No
Package
OLGA
Package dimension
l
3.65
mm
w
2.6
mm
h
1.09
mm
Input/Output Voltage
VDD
Ordering codes
Product Type | Description | Order No. | Availability |
---|---|---|---|
AS7331-AQFM | OLGA16 Tape & Reel 1000 pcs/reel | Q65114A3064 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
By clicking this button you will be transferred to the dedicated site of our logistics partner, Mouser Electronics where your purchase can be completed. Your payment and order details provided for this purpose will be shared between Mouser Electronics and ams OSRAM. More details on the data processing in question can be found in the Privacy Policy of the Mouser shop.
|
AS7331-AQFT | OLGA16 Tape & Reel 5000 pcs/ree | Q65114A3065 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
By clicking this button you will be transferred to the dedicated site of our logistics partner, Mouser Electronics where your purchase can be completed. Your payment and order details provided for this purpose will be shared between Mouser Electronics and ams OSRAM. More details on the data processing in question can be found in the Privacy Policy of the Mouser shop.
Buy From Distributors:
Mouser
Buy now
|
Downloads
Datasheets
Datasheet
Technical documents
Technical note
Environmental documents
RoHS certificate
Images
Images
Images
Images
Block diagram
Software
Evaluation software
