Details
Features
- Color (RGB) and ambient light sensor with integrated UV/IR blocking filters
- IRBeam optical pattern generator
- Proximity detection with adaptive dynamic range, automatic crosstalk cancelation, and ambient light rejection
- Integrated optical module
Benefits
- Enables highly accurate color and ambient light sensing under varying lighting conditions
- Supports mobeam™ and universal remote control functionality
- Low profile, small footprint package reduces board space – ideal for small devices
Parameters
Function
color sensing
proximity detection
Supply voltage
1.8
V
min.
1.7
V
max.
2.0
V
Interface
input
I²C slave (400kHz)
output
I²C slave (400kHz)
Operating ambient temperature
min.
-30
°C
max.
85
°C
Emitter quantity
1 integrated
Integrated diffuser
No
Package
Module
Package dimension
l
5.0
mm
w
2.0
mm
h
1.0
mm
Input/Output Voltage
1.8 V
Application fields
