ams AS5145_DEM_SN Demonstrator kit

ams AS5145_DEM_SN Demonstrator kit
×

Description

The AS5145 Demo Kit allows you an easy-to-use evaluation of the principle function of the AS5145 automotive magnetic rotary position sensor without additional hardware and software effort. This kit consists of a reference magnet with its holder and an LCD display. It is suitable for mechanical and hardware reference design. The AS5145 Demo Kit can be used in standalone mode through LCD display or in combination with the AS5000-GUI PC software in order to be able evaluating all the functionalities of the AS5145 magnetic position sensor.
User guide
Contact us Support

Downloads

User guides

AS5045_AS5145_UG000227_1-00

User guide
EN
DE
CN
JP

Images

Related Products

ams AS5145A Rotary Sensor

The AS5145A is a contactless magnetic rotary position sensor for accurate angular measurement over a full turn of 360° and over an extended ambient temperature range of -40°C to 150°C. The absolute angle measurement provides instant indication of the magnet’s angular position with a resolution of 0.0879° = 4096 positions per revolution via a serial bit stream and as a PWM signal. The incremental output (=ABI-interface) is preprogrammed for 10 bit = 1024 positions.With two decades of magnetic sensor system know-how, we have broad experience in selecting the most suitable magnets. ams experts recommend the following magnet suppliers.
Details and Datasheet

ams AS5145B Rotary Sensor

The AS5145B is a contactless magnetic rotary position sensor for accurate angular measurement over a full turn of 360° and over an extended ambient temperature range of -40°C to 150°C. The absolute angle measurement provides instant indication of the magnet’s angular position with a resolution of 0.0879° = 4096 positions per revolution via a serial bit stream and as a PWM signal. The incremental output (=ABI-interface) is preprogrammed for 12 bit = 4096 positions.With two decades of magnetic sensor system know-how, we have broad experience in selecting the most suitable magnets. ams experts recommend the following magnet suppliers.
Details and Datasheet

ams AS5145H Rotary Sensor

The AS5145H is a contactless magnetic rotary position sensor for accurate angular measurement over a full turn of 360° and over an extended ambient temperature range of -40°C to 150°C. The absolute angle measurement provides instant indication of the magnet’s angular position with a resolution of 0.0879° = 4096 positions per revolution via a serial bit stream and as a PWM signal.With two decades of magnetic sensor system know-how, we have broad experience in selecting the most suitable magnets. ams experts recommend the following magnet suppliers.
Details and Datasheet
