Details
Features
- High speed up to 80 kLines/s x 2 Lines at full resolution, for all variants
- From 2k to 16k resolutions available
- Re-use of the same camera interface across different Dragster variants
- High mechanical stability and planarity of the die.
- Improved camera quality compared to CCD based products
Benefits
- Higher machine production speed having up to two simultaneously and fully independently operated lines
- Most complete sensor family on the market. Complete coverage of high resolution and high scanning speeds
- Easy integration with system resolution scalability
- Easy integration with system resolution scalability COB/Invar package
- Completely digital sensor
Parameters
Resolution
0.016
MP
Shutter type
Global
Dynamic range
66.4
dB
Function
line scan
Integration time
min.
2
µs
Package
Invar
LCC Ceramic
Cover glass
Anti-reflective coating
CFA option
Mono
RGB
ADC mode
8
bit
9
bit
10
bit
11
bit
12
bit
Interface
output
Parallel / CMOS TTL
Line rate
max.
80000
lines/s
